Watlow Anafaze CLS200 Multiloop Process Control
|
|
 CLS200: Compact
Loop System,
Providing Powerful
Control in a 1/8
DIN
Package
Product
Spec Sheet
Product
Manual
|
Description
|
|
|
- Integrate with other controllers
and software The Watlow Ahafaze CLS200 senes is
a powerful line of controllers, combining performance
and flexibility with compact design. The 4, 8, and
16 loop versions provide complete control solutions
for a broad range of applications. Support for multiple
types of sensor inputs is available, including thermocouples,
RTDs, linear voltage, current and frequency. Each
controller can operate as a stand-alone system,
and includes built-in serial communications for
computer interface and data acquisition. Optional
programmable ramp and soak features allow complex
batch processing and sequencing. An enhanced features
option offers cascade control, ratio control, differential
control, process variable retransmit, and remote
analog set point.
|
|
|
|
Features
|
|
|
- PID control of up to 16
heat and cool loop
- Auto-tune
- Menu-guided operation with
full text display, makes control easy to operate
- Eight jobs stored and recalled
- Multiple and mixed inputs
- Sensor failure detection
- High/Iow process and deviation
alarms for each input
- 34 digital outputs with
flexible configuration: use outputs as needed for
control and alarms
- RS-232 and 485 communications.
Use software to configure and operate
|
|
