4 or 8 Loops

Control and Logic

Product Spec Sheet

Product Manual

Description

 The Watlow Anafaze CPC400 controllers provide performance and flexibility in a compact design and integrate full-featured closed-loop control with user-written logic. Programmable logic can interact with closed-loop control and operate I/O independently.

Four and eight loop versions offer complete control solutions for a broad range of applications. The CPC400 supports thermocouples, RTDs, linear voltage, current and frequency. Built-in diagnostics automatically detect sensor failures including open, shorted and reversed conditions. I/O can also be utilized for closed-loop control, alarms and user programs.

Using the built-in communications port, system designers can interface one or more controllers to a host computer for operator controls and data acquisition The CPC400 offers PID, cascade, ratio and differential control strategies. Process variable retransmit and remote analog setpoint can be used to integrate the CPC400 with other devices such as chart recorders.

The CPC400 carries the CE mark and is UL® listed.

Features

• Programmable logic
• Compact 1/8 DIN case
• LogicPro support
• Watview support
• Separate setpoints for high deviation and low deviation alarms
• Keypad with 4 direction navigation arrows, loop + , loop -, escape symbol, “i” help and revised menu structure
• Help screens
• Latched HW alarms
• Manual reset
• Modbus RTU Communication for integration into existing SCADA systems
