- The Watlow Series 982 vertical
1/8 DIN ramping control and its companion, the horizontal
Series 981, offer four-file / 24-step program capability,
or easy-to-use non-ramping set point operation.
The control is designed with most typical programming
needs in mind. The Series 981/982 is among the most
easy-to-use ramping controls.
-
- Ramping operations include
four files with six steps in each file. Programming
options include ramp-rate or time-based profiles,
guaranteed soak deviation, program looping and program
status selection after power outage. The files may
be linked to create a single 24-step program.
-
- The primary analog input
accepts 11 different thermocouple types, RTD or
scalable process inputs. A second analog input can
be factory configured for a slidewire feedback input
common in gas valve control. With up to two event
inputs, the Series 981/982 offers remote program
start or hold capability and allows the operator
to program a wait-for event.
-
- The Series 981/982 is packaged
with a NEMA 4X front panel to withstand harsh environments,
four inch case depth and touch-safe wiring terminal.
-
- The Series 981/982 features
a three-year warranty and four day shipment, on
all model, in limited quantities.
|
