Watlow Series CZR Solid State Relay

Compact Design

Provides Versatile

Solid State Option



Product Spec Sheet

Product Manual

Description



 The new Series CZR solid state contactor from Watlow provides a low-cost, highly compact and versatile solid state option for controlling electric heat. With DIN rail and back panel mounting standard on every control, the CZR allows for simple and quick installation.

The extensive capabilities of the Series CZR include single-phase, 24 to 50 amp zero-cross and random switching up to 600V (see output rating curve). The unique integrated design removes the guesswork associated with selecting a proper heat sink and precise terminations for the application.

This controller holds many agency approvals and is ideal for applications that require ULŪ, CSA and CE approvals.

Series CZR contactors are available in voltage, current and (ac/dc) input contactor versions. All configurations are model number dependent and factory selectable.

The Series CZR is reliably backed by a two-year warranty from Watlow Contols

Features



  •  DIN rail or standard panel mount
  • Versatile, quick and low-cost installation
  • Compact size Reduces panel space; less cost
  • Touch-safe terminals Increases safety for installer and operator
  • Mercury Free Environmentally safe
  • Faster switching with solid state
  • Saves energy and extends heater life
  • ULŪ508 recognized, CSA LR700195 certified and
    CE 60950, VDE 0805 applied for
  • Back-to-back SCR design
  • Rugged design
