Din A Mite Family Overview

Feature	DIN-A-Mite A	DIN-A-Mite B	DIN-A-Mite C	DIN-A-Mite D
1-Phase**	Up to 25 A @600VAC	Up to 40A @600 VAC	Up to 80A @600 VAC	Up to 100A @600 VAC
3-Phase 2 Leg**	No	Up to 33A @ 600 VAC	Up to 80A @ 600 VAC	Gang 2 Units
3-Phase 3 Leg*	No	Up to 22 A @600VAC	Up to 70A @ 600 VAC	Gang 3 Units
VAC & VDC Burst Fire Input	24,120,&240 VAC 4.5-32 VDC	24,120,&240 VAC 4.5-32 VDC	24,120,&240 VAC 4.5-32 VDC	24,120,&240 VAC 4.5-32 VDC
Multi zone VDC Input	No	Yes	Yes	No
4-20 mA DC Variable Time Base Output	Yes	Yes	Yes	Yes
Phase Angle Fire Output***	No	No	Yes (1 Phase Only)	No
Manual Control via Potentiometer input,or linear voltage input	No	No	Yes	No
Shorted SCR Detector	No	Yes	Yes	Yes
Load Current Monitor CTs	No	No	No	Yes
Open Heater Alarm	No	No	Yes (S Input Only)	Yes
On Board Semiconductor Fusing	No	No	No	Yes
DIN Rail Mount	Yes	Yes	Yes	Yes
Sub-Panel Mount	Yes	Yes	Yes	Yes
Through Cabinet Heatsink Mount	No	No	Yes	No
Electrically Touch Safe	Yes	Yes	Yes	Yes
Back to Back SCR Design	Yes	Yes	Yes	Yes
UL 508/C-UL/VDE 0160 CE with filter	Yes	Yes	Yes***	Yes
Dimensions (Inches)	3.7"H x 1.8"W x 3.9"D	3.7H x 3.1W x 4.9D	6.0H x 3.1W x 5.7D	7.25H x 2.5W x 9.4D
Controller Weight	.71 lb	1.5 lb	2.6 lb / 3.2lb (with Fan)	6.5 lb
